ProcessMetal powder-bed fusionПример · уточняется / 「示例、待确认」
MaterialAl or Ni alloyПример · уточняется / 「示例、待确认」
FormWedge housing, perforated faceПример · уточняется / 「示例、待确认」
PortsConical boss / face gridПример · уточняется / 「示例、待确认」
| Item | Typical value | Note |
|---|---|---|
| Post | Support removal, optional CNC seals | Пример · уточняется / 「示例、待确认」 |
Design intent
This example shows a hollow wedge body where a face grid and a small port share one printed blank.
- Keep seal lands thick enough for post-machining if leak-tightness matters
- Confirm hole-grid diameter and pattern on the drawing
- Do not invent pressure ratings or certifications on this page
Manufacturing notes
Perforations need reliable powder removal and inspectable walls. Mark which faces are sealed.
All dimensions and alloys on this page are examples to be confirmed — not a quotation.
What to put on the RFQ
- Preferred alloy family
- Which faces are critical for flatness or leak check
- Any NDT expectations (state them; we do not invent certifications)
Пример · уточняется / 「示例、待确认」
Next step
Есть похожая деталь?
Загрузите САПР и чертежи. Инженер проверяет материалы, допуски и отделку перед ценообразованием.
