Кейс детали · Metal 3D Printing

Авиационный фланцевый корпус Metal AM

Aviation flange housing blank with a large bolted ring and upper ports — for discussing printable housings and which flange faces need machining after build.

Metal additive aviation flange housing blank with large bolted ring
Photo courtesy xa-blt.com (authorized for 3DWK use). 3DWK part case — brand remains 3DWK; not a BLT storefront listing.
  1. 01

    Flange-housing notes

    Bolt circles and ports dominate secondary machining stock planning.

    • Call flatness and bore class on the RFQ
    • Keep inspection access in early articles
  2. 02

    Honesty bar

    No claimed aircraft programs, pressure ratings, or OEM brands on this page.

Типовая спецификация

Отправные точки для этой детали

Process
Metal powder-bed fusion
Form
Flange housing with bolted ring
Interfaces
Bolt circle + upper ports
Post
Mill flange / bore faces TBD
Note
Geometry sample
Metal additive aviation flange housing blank with large bolted ring
Photo courtesy xa-blt.com (authorized for 3DWK use). 3DWK part case — brand remains 3DWK; not a BLT storefront listing.
